statamic-cap - a Statamic Addon

Statamic addon to integrate Cap — a self-hosted proof-of-work CAPTCHA — into Statamic forms.

Requirements

PHP 8.2+
Statamic 5.x or 6.x
A self-hosted Cap instance

Installation

composer require oliweb/statamic-cap

Assets (JS + CSS) are served automatically by the addon via dedicated routes. No vendor:publish required.

Configuration

Via the Statamic CP

Go to Tools > Cap CAPTCHA in the Statamic control panel.

Field	Description
Cap Endpoint URL	Full URL of your Cap instance, including the site key (e.g. `https://cap.example.com/your-site-key/`)
Token Field Name	Name of the hidden field injected by the widget (default: `cap-token`)
Timeout (seconds)	Request timeout for `/siteverify` calls (default: `5`)
Fail Open	If enabled, allows requests through on Cap communication errors
Hide Attribution Link	If enabled, hides the "Cap" attribution link at the bottom right of the widget
Allow CDN fallback for WASM	If enabled, falls back to `cdn.jsdelivr.net` when the local WASM has not been published. Disabled by default — see note below.

Breaking change (v1.8+) — WASM CDN fallback: prior to this version, a missing local WASM file silently redirected to cdn.jsdelivr.net. This fallback is now opt-in: with Allow CDN fallback for WASM disabled (the new default), a missing local WASM returns a 503 instead. The recommended solution is to publish the WASM locally once via php artisan cap:publish-wasm. Enable the CDN fallback only if you explicitly accept the external dependency.

Important — Cap secret: the secret is not configurable from this panel. It must be set exclusively via the CAP_SECRET environment variable in .env (or via the published oliweb/laravel-cap configuration). Exposing the secret in the CP panel is a security risk; it is read directly from config('cap.secret') at verification time.

Config key resolution: endpoint, token_field, timeout, and fail_open are read from config('statamic-cap.*'), with config('cap.*') as a fallback for values not overridden in the CP. secret is sourced exclusively from config('cap.secret') and is never read from the statamic-cap namespace. If a verification call uses the wrong endpoint after a CP change, check that the YAML file has been written to storage/statamic/addons/statamic-cap.yaml and that the config cache has been cleared.

Settings are saved to storage/statamic/addons/statamic-cap.yaml.

Via environment variables

Environment variables serve as default values and are overridden by CP settings for editable fields.

# Configurable from the CP panel as well
CAP_ENDPOINT=https://cap.example.com/your-site-key/
CAP_TOKEN_FIELD=cap-token
CAP_TIMEOUT=5
CAP_FAIL_OPEN=false
CAP_HIDE_ATTRIBUTION=false
CAP_WASM_CDN_FALLBACK=false

# Secret — via .env or config/cap.php only (never from the CP panel)
CAP_SECRET=your-secret-key

Usage

Antlers tags

Tag	Description
`{{ cap }}`	Renders the `<cap-widget>` with the configured endpoint
`{{ cap:scripts }}`	Injects `window.CAP_CUSTOM_WASM_URL`, `window.CAP_CUSTOM_HASHWX_URL` + `<script type="module">` for the widget
`{{ cap:styles }}`	Widget CSS `<link>` tag
`{{ cap:config }}`	`<script>` exposing `window.CAP_API_ENDPOINT` and `window.CAP_TOKEN_FIELD`
`{{ cap:frame }}`	Renders the Cap widget in a hidden iframe with a permissive CSP — keeps the parent page strict (no `'unsafe-eval'`)

Standard widget mode

Load assets in the layout and add the widget to a Statamic form:

<head>
    {{ cap:styles }}
</head>
<body>

    {{ form:create handle="contact" }}
        {{ cap }}
        <button type="submit">Send</button>
    {{ /form:create }}

    {{ cap:scripts }}
</body>

The widget automatically injects a hidden cap-token field into the parent form upon verification.

{{ cap:scripts }} always injects window.CAP_CUSTOM_WASM_URL pointing to the local WASM route — no external request at runtime.

Programmatic mode

Use {{ cap:config }} to expose the endpoint in JavaScript, then instantiate Cap directly without rendering a visible widget:

<head>
    {{ cap:styles }}
</head>
<body>

    {{ cap:config }}
    {{ cap:scripts }}

    <form method="POST" action="/contact">
        <input type="hidden" name="cap-token" id="cap-token">
        <button type="submit" id="submit-btn">Send</button>
    </form>

    <script type="module">
    document.getElementById('submit-btn').addEventListener('click', async (e) => {
        e.preventDefault();

        const cap = new Cap({ apiEndpoint: window.CAP_API_ENDPOINT });
        const { token } = await cap.solve();

        document.getElementById('cap-token').value = token;
        e.target.closest('form').submit();
    });
    </script>

</body>

Cap automatically creates a hidden cap-widget element in the background. No visible widget is rendered.

window.CAP_API_ENDPOINT and window.CAP_TOKEN_FIELD are set by {{ cap:config }} from the PHP configuration — no JavaScript hard-coding required.

Iframe mode (strict CSP — no `'unsafe-eval'`)

When Cap's instrumentation is enabled, the widget requires 'unsafe-eval' in script-src. If your page enforces a strict CSP, use {{ cap:frame }} instead: it renders the widget inside a hidden iframe (/cap-frame) with its own permissive CSP, keeping the parent page clean.

{{-- No {{ cap:scripts }} or {{ cap:styles }} needed --}}

{{ form:create handle="contact" }}
    {{ cap:frame }}
    <button type="submit">Send</button>
{{ /form:create }}

This renders a hidden <input type="hidden" name="cap-token">, an invisible <iframe src="/cap-frame">, and a <script> that bridges the two via postMessage.

Token flow:

Parent page (strict CSP)              iframe /cap-frame (permissive CSP)
      │── postMessage(cap:start) ──►  │  widget.solve()
      │◄── postMessage(cap:token) ──  │  token
      │  fills #cap-frame-token       │

Programmatic trigger — {{ cap:frame }} exposes window.capSolve() on the parent page:

// Trigger Cap resolution from Alpine, Vue, etc.
window.capSolve();

// Listen for the token (in addition to the hidden input auto-fill)
window.addEventListener('message', (e) => {
    if (e.origin !== window.location.origin) return;
    if (!e.data || e.data.type !== 'cap:token') return;
    myForm.submit(e.data.token);
});

With nonce:

{{ cap:frame nonce="{ $cspNonce }" }}

Multiple instances — pass a unique id when several forms share the same page:

The custom id must satisfy: pattern ^[A-Za-z][A-Za-z0-9_-]*$, max 64 characters. An invalid value throws an InvalidArgumentException at render time.

{{-- Login form --}}
{{ cap:frame id="login-cap" }}
{{-- or with nonce: {{ cap:frame nonce="{ $cspNonce }" id="login-cap" }} --}}

{{-- Contact form --}}
{{ cap:frame id="contact-cap" }}

Each instance gets its own namespaced trigger function:

Tag	iframe / input ids	trigger
`{{ cap:frame }}`	`cap-frame` / `cap-frame-token`	`window.capSolve()`
`{{ cap:frame id="login-cap" }}`	`login-cap` / `login-cap-token`	`window['capSolve_login-cap']()`

/cap-frame route is registered automatically by oliweb/laravel-cap. Its Content-Security-Policy includes 'unsafe-eval', 'wasm-unsafe-eval', blob:, and img-src data: — everything Cap needs — while frame-ancestors 'self' prevents embedding from external origins.

Instrumentation and strict CSP

Cap's optional instrumentation feature (enabled per site key in the Cap admin dashboard) calls eval() and new Function(), which are blocked by a script-src without 'unsafe-eval'.

If instrumentation is enabled and 'unsafe-eval' is absent from your CSP, the widget reports [instr_timeout] and Cap returns HTTP 429, making every verification attempt fail.

Recommended workaround: use {{ cap:frame }} as described above.

Alternatives:

Disable instrumentation for the site key in the Cap admin dashboard.

Add 'unsafe-eval' to your script-src (weakens the parent page CSP).

See also: tiagozip/cap#268

With CSP nonce

{{ cap:config nonce="{ $cspNonce }" }}
{{ cap:scripts nonce="{ $cspNonce }" }}
{{ cap nonce="{ $cspNonce }" }}

CSP headers

The widget relies on Web Workers and WebAssembly. A strict CSP must include:

Content-Security-Policy:
  script-src 'nonce-{nonce}' 'strict-dynamic';
  worker-src blob:;
  wasm-unsafe-eval;
  connect-src 'self';

worker-src blob: — required because the widget spawns workers via Blob URLs. wasm-unsafe-eval — required for WebAssembly hash computation. connect-src 'self' — sufficient when WASM is served locally (see below).

Automatic validation

Token verification is automatic: the addon listens to Statamic's FormSubmitted event and rejects the submission if the token is invalid or missing. No additional configuration required.

On failure, a validation error is returned with the message statamic-cap::messages.validation_failed.

Disabling Cap on a specific form

By default, every form submission is verified. To exclude a specific form (e.g. an internal admin form that never renders the Cap widget), use the Cap tab in Statamic's form editor in the control panel and toggle Disable Cap on.

Alternatively, add cap_disabled: true directly as a top-level key in the form's YAML file (useful for Git-managed form configurations):

# resources/forms/my_internal_form.yaml
title: My Internal Form
cap_disabled: true
fields:
  -
    handle: name
    field:
      type: text

When cap_disabled: true is present, the listener exits immediately without making any network request to Cap's /siteverify endpoint.

Non-breaking: forms that do not have cap_disabled in their YAML are protected exactly as before. The absence of the key is treated as cap_disabled: false.

Local WASM (strict CSP)

By default, {{ cap:scripts }} injects window.CAP_CUSTOM_WASM_URL pointing to the /vendor/statamic-cap/cap_wasm_bg.wasm route. As of v1.8.0, this route returns a 503 if the local WASM has not been published — CDN fallback is opt-in and disabled by default (see the Breaking change note above).

For fully self-hosted operation with no external requests, download both WASM files locally:

php artisan cap:publish-wasm

The command downloads and saves:

File	Path	Purpose
`cap_wasm_bg.wasm`	`storage/app/statamic-cap/cap_wasm_bg.wasm`	PoW computation (rsw keys)
`hashwx.wasm`	`storage/app/statamic-cap/hashwx.wasm`	PoW computation (hashwx keys — new default since Cap 3.1.12)

{{ cap:scripts }} automatically injects both window.CAP_CUSTOM_WASM_URL and window.CAP_CUSTOM_HASHWX_URL pointing to the corresponding local routes. The CSP can then be limited to connect-src 'self' without whitelisting jsDelivr.

Upgrading

After composer update oliweb/laravel-cap, re-run the command to refresh both WASM files to the versions bundled with the updated package:

php artisan cap:publish-wasm

Translations

Translations are available in English, French, and German. Strings cover validation, error messages, widget labels, and the CP settings page.

To customise them, copy and edit the file in your project:

lang/vendor/statamic-cap/{locale}/messages.php

License

MIT — see LICENSE
